Patented level indicator – With the patented level run indicator, the operator can visually verify the snow blower is properly leveled before each use.
Hydraulically operated chute rotation – Hydraulically operated chute rotation with sprocket drive allows operator to change direction of snow discharge from the seat.
Intell-Attach™ – The Intell-Attach™ system allows the Kubota SVL97-3 to intelligently recognize a Kubota by Land Pride Attachment when equipped with an Intell-Attach tag. Once programmed, the communication between the receiver and tag automatically recognizes the capabilities of the attachment and adjusts the power unit to match. Real time feedback between the attachment and SVL97-3 helps the operator maximize performance and speed machine set-up.
Large main housing – Ability to handle large drifts. Large impeller diameter – The ability to move and throw material farther. Sprocket driven chute rotator – Allows operator to change chute rotation angle within a 220 Deg discharge pattern. 3/8 In. Auger Flighting – Stands up to sever use.
Bolt-on reversible and replaceable cutting edge – Improves service life of snow blower by protecting the unit from bottom wear and absorbing some of the shock when hitting solid objects. The blade can be rotated 180 Deg to double its life and can be replaced when both edges are worn out.
Universal quick attach hitch, hydraulic deflector. Greaseable auger end bearing – Less drag on the power train and extends life of unit.
Drive and Control System: Hydraulic motors with electric over hydraulic, Hydraulic requirements: low volume motor option: 12 – 19 Gpm, Hydraulic requirements: medium volume motor option: 20 – 26 Gpm, Hydraulic requirements: high volume motor option: 27 – 33 Gpm, Hydraulic pressure rating: 2500 – 3500 psi.
Hitch: Skid steer/loader mounting plate, Main housing material: 10 gauge, Side plate material: 3/16 In., Chute opening at the base: 10 In., Impeller housing depth: 8 In.
Impeller Diameter: 24 In., Number of impeller blades: 4, Auger diameter: 16 In., Number of auger paddles: 4
Cutting edge: Bolt-on, reversible, and replaceable full-length cutting edge, Skid shoes: bolt-on, adjustable & replaceable, Chute rotation: 220 Deg (hydraulically driven sprocket), Spout deflector: hydraulic operation, Spout deflector cylinder: double acting 2 In. x 4 In. x 1-1/2 In. rod.
